Budnick Converting ®
tesa tape inc
4965
Double Coated Polyester Bonding Tape
tesa 4965 is an 8 mil transparent double-sided self-adhesive tape consisting of a PET backing and a modified acrylic adhesive with a red polypropylene release liner. The adhesive system is especially resistant to plasticizers and offers a secure bond even at elevated temperatures. It is sometimes referred to as tesa Red because of the red liner. tesa 4965 can be slit or die cut into custom parts. It is used for plastic, metal, and wood bonding where temperature resistance or clarity are key requirements. tesa 4965 is one of the most versatile permanent and critical bonding tapes on the market. tesa 4965 is ideal for creating die-cut parts for mounting and bonding applications
Converting Services
- Precision Cutting
- Die Cutting
- Slitting
- Printing
- Laminating and Coating
- Spooling and Finishing
- Consulting & Process Audit
- Prototyping
- Inventory Management
At Budnick, we specialize in custom converting these materials into labor saving, user-friendly parts.
| Backing/Carrier | PET - Polyester |
|---|---|
| Adhesive | Acrylic |
| Thickness | 8.1 Mils |
| Tensile | 11.42 lbs/in |
|---|---|
| Elongation | 50.00% |
| Adhesion (liner) | 127.91 oz/in |
| Adhesion (unwind) | 127.91 oz/in |
| Min. Application Temp | 40° F |
|---|---|
| Min. Service Temp | 0° F |
| Max Short-Term Temp | 392° F |
| Max Long-Term Temp | 212° F |
Product Features
- Transparent adhesive with red polypropylene release liner
- Secure bond at elevated temperatures
- Suitability for most demanding applications such as heavy stress, high temperatures or critical substrates
- Reliable bond even to LSE substrates
- Immediate usability right after assembly
- UV, aging, and plasticizer resistance
- High tack coupled with high adhesive strength
- 4965 is recognized according to UL standard 969. UL file: MH 18055
- Often referred to as tesa Red
Markets Served
- Automotive
- Appliance
- Electronics
- Commercial printing
- Signage, Banners, & Printing
- Medical Device
- Extruders of Plastic and Rubber
Adhesive Tape Applications
- Mounting of ABS plastic parts in the car industry
- Mounting of rubber/EPDM profiles
- Mounting of decorative profiles and furniture profiles
- Mounting of cell phone components
- Mounting of battery packs, lenses and touch-screens in electronic devices
- Permanent mounting of PP to a polyurethane, foot guard to foot plate
- Attachment tape for blinds and shades
- Mounting and bonding applications in the appliance industry
- Excellent for custom die cut tape parts
Adhesive Tape Colors
- Transparent
Data provided by Budnick Converting, Inc.
The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.
It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.
Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.
Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.
