F9500-STD

Unsupported Rubber Laminating Adhesive

F9500-STD is a high performance, unsupported rubber based adhesive designed for extremely difficult assembly aid wrap applications on low surface energy plastics where parts will be subjected to high temperatures during transportation. F9500-STD uses RP100 adhesive and will bond well to a wide variety of non-plasticized materials and should not be used in applications where direct exposure to UV light is required. RP100 has been tested to the following automotive specifications: ESB-M11P8-A, ESA-M11P19-A, MS-CC235, MS-CC211, GM3607M Type I, GM3622M Type IV, GMW14892.

Backing/Carrier
Adhesive Rubber
Thickness 4.5 Mils
Tensile
Elongation
Adhesive Activation Pressure
Adhesion (unwind) 270 oz/in
Min. Application Temp 50° F
Min. Service Temp -35° F
Max Short-Term Temp 225° F
Max Long-Term Temp 180° F

Product Features

  • Uses RP100 adhesive system
  • RP100 has been tested to the following automotive specifications: ESB-M11P8-A, ESA-M11P19-A, MS-CC235, MS-CC211, GM3607M Type I, GM3622M Type IV, GMW14892
  • Bonds well to a wide variety of materials

Markets Served

  • Automotive
  • Aerospace
  • Marine
  • Recreational

Adhesive Tape Applications

  • Designed for extremely difficult assembly aid wrap applications

We're sorry, there are no sizes currently available for this product.

Data provided by Budnick Converting, Inc.

The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.

It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.

Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.

Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.
