Tiger Differential
Acrylic Silicone Double Coated Tape
Tiger Differential Acrylic Silicone DC is a double-coated tape featuring a polyester film carrier with an aggressive acrylic adhesive on the face side and a high-performance silicone adhesive on the liner side. This differential adhesive construction is designed to quickly and efficiently bond dissimilar materials.
Converting Services
- Precision Cutting
- Die Cutting
- Slitting
- Printing
- Laminating and Coating
- Spooling and Finishing
- Consulting & Process Audit
- Prototyping
- Inventory Management
At Budnick, we specialize in custom converting these materials into labor saving, user-friendly parts.
| Backing/Carrier | |
|---|---|
| Adhesive | Acrylic |
| Thickness | 5 Mils |
| Tensile | |
|---|---|
| Elongation | |
| Adhesion (liner) | 50 oz/in |
| Adhesion (unwind) | 60 oz/in |
| Min. Application Temp | 50° F |
|---|---|
| Min. Service Temp | |
| Max Short-Term Temp | 350° F |
| Max Long-Term Temp | 250° F |
Product Features
- Excellent Adhesion to Silicone and Rubber
- Resistant to UV, Humidity, Plasticizer and Solvents
- Performs in a Wide Range of Temperatures
- User Friendly Application when Die Cutting
Markets Served
- Automotive
- Aerospace
- Commercial
- Signage, Banners, & Printing
- Medical Device
- Industrial
- Extruders of Plastic and Rubber
Adhesive Tape Applications
- Bonding and Mounting of Dissimilar Products
- Used in Gasket Manufacturing
- Splicing and Fabrication
- Laminating
Data provided by Budnick Converting, Inc.
The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.
It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.
Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.
Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.
