tesa tape inc 52338
Photopolymer Plate Mounting For Flexographic Print

General Information
52338 is a 15 mil, soft PVC, photopolymer plate mounting tape for high quality flexographic printing. It is designed for use in wide web flexo printing particularly on solid areas and line work. It unwinds smoothly, despite its relative thickness, to ensure easy cylinder coverage. The high adhesion and good shear resistance of this tape ensure that there is no plate movement or edge lift problems even at high speeds and on extended runs. The embossed polypropylene liner prevents the formation of air bubbles when plate mounting. 52338 exhibits excellent resistance to all commonly used solvent systems used in flexographic printing. The double linered version is (PV3).
Backing Adhesive
(unwind)		 Thickness
(total)		 Liner Type
(outer)
PVC - Polyvinylchloride Rubber 15.00 mil Polypropylene (white, embossed)

Adhesion to Steel
180° Peel		 adhesion to steel 180° peel - liner side Tensile Strength Elongation Percent
63.00 oz/in 63.00 oz/in

Min Application
Temp		 Min Service
Temp		 Max Short-Term
Temp		 Max Long-Term
Temp

Adhesive Tape Features
  • Adhesion strength=17.5N/25mm
  • Embossed liner ensures no air bubbles
  • Chemical resistant
  • High adhesion
  • Good shear resistance
  • Smooth unwind
  • High inital tack
Adhesive Tape Applications
  • Printing of polyethylene film such as potato bags, hot dog & sausage packaging, frozen & bakery food items packaging
Adhesive Tape Markets Served
Adhesive Tape Colors
  • Black

Comparable products

tesa tape inc 52338 View Datasheet
Photopolymer Plate Mounting For Flexographic Print
Backing Adhesive Thickness Adhesion
 PVC - Polyvinylchloride   Rubber   15.00mil   63.00oz/in
3M 414 View Datasheet
Double Coated Tape with a Fabric Backing
Backing Adhesive Thickness Adhesion
       mil   oz/in
3M 412 View Datasheet
Double Coated Tape with a Fabric Backing
Backing Adhesive Thickness Adhesion
       mil   oz/in
