Budnick Converting ®
3M
VHB™ Tape 4622
45mil White General Purpose Acrylic Foam Tape
3M™ VHB™ Tape 4622 is a general purpose, double sided acrylic foam tape. It is a double-coated pressure sensitive adhesive tape for bonding a variety of materials. The non-liner side adhesive bonds to metals and high surface energy plastics. The liner side adhesive has the same properties but it also has the ability to bond to many medium surface energy plastics, composites and painted surfaces.
Converting Services
- Precision Cutting
- Die Cutting
- Slitting
- Printing
- Laminating and Coating
- Spooling and Finishing
- Consulting & Process Audit
- Prototyping
- Inventory Management
At Budnick, we specialize in custom converting these materials into labor saving, user-friendly parts.
| Backing/Carrier | Acrylic Foam |
|---|---|
| Adhesive | Acrylic |
| Thickness | 45 Mils |
| Tensile | 70.00 lbs/in |
|---|---|
| Elongation | |
| Adhesion (liner) | 320 oz/in |
| Adhesion (unwind) | 320 oz/in |
| Min. Application Temp | 50° F |
|---|---|
| Min. Service Temp | |
| Max Short-Term Temp | 250° F |
| Max Long-Term Temp | 200° F |
Product Features
- White, double-coated pressure sensitive adhesive tape for bonding a variety of materials.
- It has an acrylic foam adhesive carrier
- It is 0.045in Thick
- It has a 0.004in Green Polyethylene release liner
- It has a density of 45 lb./sq ft.
- It is available at a minimum of 1/2in wide
- Core size of 3.0 inch I.D.
- Static shear at 72° holds 10,000 minutes (1,00g/.5 sq. in.)
- The non-liner side bonds to metals and high surface energy plastics, while the liner side adhesive bonds to metals and high surface energy plastics and also has the ability to bond to many medium surface energy plastics, composites and painted surfaces.
- Liner side adhesive=Medium surface energy acrylic
- Non-Liner side adhesive=High surface energy acrylic.
- Creates a permanent seal against water, moisture and more
- Virtually invisible fastening keeps surfaces smooth
Markets Served
- Aerospace
- Appliance
- Industrial
- Industrial
- Truck and trailer body
- Automotive
- Construction
- Electronics
- Medical Device
Adhesive Tape Applications
- Bonds to a variety of materials
- Bonds to metals and high surface energy plastics
- Bonds to metals and high energy plastics as well as the ability to bond to many medium surface energy plastics, composites and painted surfaces.
- Creates a permanent seal against water, and moisture
Adhesive Tape Colors
- White
Comparable Products
Data provided by Budnick Converting, Inc.
The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.
It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.
Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.
Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.
