tesa tape inc 4970
Double Coated White UPVC

General Information
tesa 4970 is a 9.4 mil, white, double coated tape, consisting of a PVC carrier and an acrylic adhesive. It is used primarily in permanent mounting applications such as decorative name plates & wooden trims. It offers a secure bond to rough surfaces and is plasticizer resistant.
Backing Adhesive
(unwind)		 Thickness
(total)		 Liner Type
(outer)
PVC - Polyvinylchloride Acrylic 9.40 mil Gold Glassine Liner

Adhesion to Steel
180° Peel		 adhesion to steel 180° peel - liner side Tensile Strength Elongation Percent
135.20 oz/in 135.20 oz/in 21.90 lbs/in 37.50%

Min Application
Temp		 Min Service
Temp		 Max Short-Term
Temp		 Max Long-Term
Temp
40 °F 0 °F 158 °F 140 °F
Adhesive Tape Features
  • Excellent combination of high tack and immediate adhesion
  • High coating weight for good bonding performance on rough or dusty surfaces
  • Resistant to plasticizers, aging, and humidity
  • Full suitability for longterm applications
  • Superior bonding characteristics
  • Strong white PVC carrier
  • Gold liner
Adhesive Tape Applications
  • Mounting trophy medallions & name plates
  • Mounting of plastic and wooden trims
  • Mounting of heavy decorative materials and displays
  • Mounting of signs, nameplates and scales
  • Laminating rubber weather stripping
  • Seam holding for sewing applications
  • Splicing PE coated cardboard
  • Attaching rubber profiles to appliance housings
  • Suitable for mounting and bonding applications in the appliance industry
Adhesive Tape Markets Served
  • Appliance
  • Extruders of Plastic and Rubber
  • Industrial
Adhesive Tape Colors
  • White

Comparable products

tesa tape inc 4970 View Datasheet
Double Coated White UPVC
Backing Adhesive Thickness Adhesion
 PVC - Polyvinylchloride   Acrylic   9.40mil   135.20oz/in
3M 927 View Datasheet
High Tack Adhesive Transfer Tape
Backing Adhesive Thickness Adhesion
 N/A   Acrylic   2.00mil   60.00oz/in
3M 950 View Datasheet
High Tack Adhesive Transfer Tapes
Backing Adhesive Thickness Adhesion
 N/A   Acrylic   5.00mil   75.00oz/in
3M 950EK View Datasheet
High Tack Adhesive Transfer Tape
Backing Adhesive Thickness Adhesion
 N/A   Acrylic   5.00mil   75.00oz/in
3M 924 View Datasheet
Adhesive Transfer Tape
Backing Adhesive Thickness Adhesion
 N/A   Acrylic   4.00mil   25.00oz/in
3M 966 View Datasheet
High Temperature Adhesive Transfer Tape
Backing Adhesive Thickness Adhesion
 N/A   Acrylic   2.30mil   145.00oz/in
3M 447DL View Datasheet
Flexomount™ Solid Printing Tapes
Backing Adhesive Thickness Adhesion
 PVC - Polyvinylchloride   Rubber   9.80mil   50.00oz/in
3M 419 View Datasheet
Multi-Purpose Double Coated Cloth Tape
Backing Adhesive Thickness Adhesion
       mil   oz/in
