TG356
Dry Adhesive Transfer Tape
TG356 is a 1.8 mil, general purpose, permanent, dry adhesive transfer tape. It is used for mounting, holding, joining/splicing paper, cardboard, textiles, plastics, leather, wood and glass.
Converting Services
- Precision Cutting
- Die Cutting
- Slitting
- Printing
- Laminating and Coating
- Spooling and Finishing
- Consulting & Process Audit
- Prototyping
- Inventory Management
At Budnick, we specialize in custom converting these materials into labor saving, user-friendly parts.
| Backing/Carrier | |
|---|---|
| Adhesive | Acrylic |
| Thickness | 1.8 Mils |
| Tensile | |
|---|---|
| Elongation | |
| Adhesive Activation | Pressure |
| Adhesion (unwind) | 25 oz/in |
| Min. Application Temp | 55° F |
|---|---|
| Min. Service Temp | 55° F |
| Max Short-Term Temp | 302° F |
| Max Long-Term Temp |
Product Features
- Use with an ATG to quickly and easily make almost any surface self adhesive
- Quick and easy to use, eliminating the cleanup and drying time associated with liquid adhesives
- Maintains its adhesion characteristics when exposed to severe environmental conditions, humidity, most solvents and ultraviolet light
Adhesive Tape Applications
- Mounting and holding various substrates
- Joining/splicing paper, cardboard, textiles, plastics, leather, wood, glass and painted surfaces
Adhesive Tape Colors
- Natural
Data provided by Budnick Converting, Inc.
The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.
It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.
Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.
Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.
