4965
Double Coated Temperature Resistant Tape



General Information
4965 is an 8 mil transparent double-sided self-adhesive tape consisting of a PET backing and a modified acrylic adhesive with a red polypropylene release liner. The adhesive system is especially resistant to plasticisers and offers a secure bond even at elevated temperatures.
Backing Adhesive
(unwind)
Thickness
(total)
Liner Type
(outer)
PET - Polyester Acrylic 8.10 mil Polypropylene (red)
Adhesion to Steel
180° Peel
adhesion to steel 180° peel - liner side Tensile Strength Elongation Percent
105.10 oz/in 127.90 oz/in 11.40 lbs/in 50.00%
Min Application
Temp
Min Service
Temp
Max Short-Term
Temp
Max Long-Term
Temp
40 °F 0 °F 392 °F 212 °F
Adhesive Tape Features
  • Transparent adhesive with red polypropylene release liner
  • Secure bond at elevated temperatures
  • Suitability for most demanding applications such as heavy stress, high temperatures or critical substrates
  • Reliable bond even to LSE substrates
  • Immediate usability right after assembly
  • UV, aging, and plasticizer resistance
  • High tack coupled with high adhesive strength
Adhesive Tape Applications
  • Mounting of ABS plastic parts in the car industry
  • Mounting of rubber/EPDM profiles
  • Mounting of decorative profiles and furniture profiles
  • Ideal for die cut operations
  • Mounting of cell phone components
  • Mounting of battery packs, lenses and touch-screens in electronic devices
  • Permanent mounting of PP to a polyurethane, foot guard to foot plate
  • Mounting and bonding applications in the appliance industry
Adhesive Tape Markets Served
  • Automotive
  • Appliance
  • Electronics/Electrical
  • Commercial printing
Adhesive Tape Colors
  • Clear
  • Transparent
Comparable products
Backing Adhesive Thickness Adhesion
 PET - Polyester   Acrylic   8.10mil   105.10oz/in
Backing Adhesive Thickness Adhesion
 PET - Polyester   Acrylic   4.00mil   25.00oz/in
Backing Adhesive Thickness Adhesion
 PET - Polyester   Acrylic   4.00mil   60.00oz/in
Backing Adhesive Thickness Adhesion
 N/A   Acrylic   2.00mil   60.00oz/in
Backing Adhesive Thickness Adhesion
 N/A   Acrylic   5.00mil   75.00oz/in
Backing Adhesive Thickness Adhesion
 N/A   Acrylic   5.00mil   75.00oz/in
Backing Adhesive Thickness Adhesion
 N/A   Acrylic   25.00mil   14.00oz/in
Backing Adhesive Thickness Adhesion
 PET - Polyester   Rubber   5.11mil   84.95oz/in
Backing Adhesive Thickness Adhesion
       mil   oz/in
Backing Adhesive Thickness Adhesion
       mil   oz/in
Backing Adhesive Thickness Adhesion
 PET - Polyester   Rubber   5.70mil   224.00oz/in
Backing Adhesive Thickness Adhesion
 PET - Polyester   Acrylic   3.98mil   70.00oz/in

The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.

It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.

Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.

Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.


Choose the surface energy of the exact surface that the adhesive will contact (e.g. if the part was painted metal, paint would be the surface energy).
