4959
General Purpose Affixing, Joining & Splicing Tape



General Information
4959 is a 4 mil, double-coated mounting and splicing tape. It is primarily used for mounting name plates, signs, attaching PDA components and splicing webs. It is equipped with a non-woven backing and is coated with a very high tack acrylic adhesive. The tissue carrier improves the shear performance versus standard unsupported transfer tapes.
Backing Adhesive
(unwind)
Thickness
(total)
Liner Type
(outer)
Non-Woven Acrylic 3.90 mil Glassine
Adhesion to Steel
180° Peel
adhesion to steel 180° peel - liner side Tensile Strength Elongation Percent
56.60 oz/in 56.60 oz/in 4.60 lbs/in 3.00%
Min Application
Temp
Min Service
Temp
Max Short-Term
Temp
Max Long-Term
Temp
40 °F 0 °F 392 °F 176 °F
Adhesive Tape Features
  • Non-woven tissue backing improves shear performance
  • Very high tack adhesive
  • Colored version for splice identification
  • Plasticizer resistant
  • Good shear resistance
  • Resistant to light and aging
  • Tackified acrylic adhesive
Adhesive Tape Applications
  • Mounting of signs, covers & name plates
  • Self-adhesive mounting of plastic bags, dispatch bags, stationery, posters & displays
  • Attaching cellular phone components
  • Mounting of door linings in the automotive industry
  • Splicing of paper and film webs
  • Process in lamination support in leather industry
Adhesive Tape Markets Served
  • Commercial printing
  • Automotive
  • Point of Purchase
  • Commercial
Adhesive Tape Colors
  • Translucent
Comparable products
Backing Adhesive Thickness Adhesion
 Non-Woven   Acrylic   3.90mil   56.60oz/in
Backing Adhesive Thickness Adhesion
 N/A   Acrylic   2.00mil   25.00oz/in
Backing Adhesive Thickness Adhesion
 N/A   Acrylic   5.20mil   113.00oz/in
Backing Adhesive Thickness Adhesion
 PVC - Polyvinylchloride   Rubber   14.90mil   50.00oz/in
Backing Adhesive Thickness Adhesion
 Tissue      3.00mil   oz/in
Backing Adhesive Thickness Adhesion
       mil   oz/in
Backing Adhesive Thickness Adhesion
 Tissue   Acrylic   3.90mil   36.00oz/in
Backing Adhesive Thickness Adhesion
 Tissue   Acrylic   3.80mil   69.00oz/in

The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.

It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.

Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.

Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.


Choose the surface energy of the exact surface that the adhesive will contact (e.g. if the part was painted metal, paint would be the surface energy).
