Ideal Tape Co. Inc. 7177
Non Silicone Polyimide Insulation

General Information
IT7177 is a 2.2 mil, polyimide film used for high temperature transformer insulation where silicone cannot be used.
Backing Adhesive
(unwind)		 Thickness
(total)		 Liner Type
(outer)
Polyimide Acrylic 2.20 mil

Adhesion to Steel
180° Peel		 Adhesive Activation Tensile Strength Elongation Percent
35.00 oz/in Pressure 30.00 lbs/in 35.00%

Min Application
Temp		 Min Service
Temp		 Max Short-Term
Temp		 Max Long-Term
Temp
40 °F 0 °F 342 °F
Adhesive Tape Features
  • Insulation resistance >1 X 10^6 meg ohms
  • Therm-X acrylic thermoset adhesive
  • Provides high puncture resistance
  • Superb high temperature performance
  • Excellent conformability
Adhesive Tape Applications
  • Transformer insulation
Adhesive Tape Markets Served
Adhesive Tape Colors
  • Amber

Comparable products

Ideal Tape Co. Inc. 7177 View Datasheet
Non Silicone Polyimide Insulation
Backing Adhesive Thickness Adhesion
 Polyimide   Acrylic   2.20mil   35.00oz/in
Permacel/Nitto Denko America P224 View Datasheet
Polyimide Electrical Insulating Tape
Backing Adhesive Thickness Adhesion
 Polyimide   Acrylic   2.50mil   20.00oz/in
Saint-Gobain K102 View Datasheet
Polyimide Tape
Backing Adhesive Thickness Adhesion
 Polyimide   Acrylic   2.50mil   25.00oz/in
Saint-Gobain K103 View Datasheet
Polyimide Tape
Backing Adhesive Thickness Adhesion
 Polyimide   Acrylic   2.50mil   25.00oz/in
3M 1205 View Datasheet
Polyimide Film with Acrylic Adhesive
Backing Adhesive Thickness Adhesion
 Polyimide   Acrylic   3.00mil   35.00oz/in
DeWal Industries 314-1 View Datasheet
Polyimide Film
Backing Adhesive Thickness Adhesion
       mil   oz/in
