LITHO 4370
***Discontinued*** Red Lithographer's Tape



General Information
***Discontinued*** LITHO 4370 is a 2.7mil (0.70mm) red PVC film with a solvent based natural rubber adhesive. This red lithographer's tape is used for pre-press stripping, edging, and opaquing applications. It absorbs UV and short-wave light. LITHO 4370 is translucent and easily repositionable , and will not curl or damage negatives upon removal.
Backing Adhesive
(unwind)
Thickness
(total)
Liner Type
(outer)
PVC - Polyvinylchloride Rubber 2.70 mil
Adhesion to Steel
180° Peel
adhesion to steel 180° peel - liner side Tensile Strength Elongation Percent
15.00 oz/in   33.00 lbs/in 75.00%
Min Application
Temp
Min Service
Temp
Max Short-Term
Temp
Max Long-Term
Temp
40 °F   158 °F
Adhesive Tape Features
  • 2.7mil Red PVC Film Tape
  • Absorbs UV and Short-Wave Light
  • Easily Repositionable
  • Will Not Curl or Damage Negatives
Adhesive Tape Applications
  • Pre-Press Striping, Edging, and Opaquing
  • General Graphic Arts Applications
Adhesive Tape Markets Served
  • Commercial printing
  • Arts & Entertainment
Adhesive Tape Colors
Comparable products
Backing Adhesive Thickness Adhesion
 PVC - Polyvinylchloride   Rubber   2.70mil   15.00oz/in
Backing Adhesive Thickness Adhesion
 Cellophane   Rubber   2.40mil   28.00oz/in
Backing Adhesive Thickness Adhesion
 UPVC - Unplasticized Polyvinylchloride   Rubber   2.40mil   36.00oz/in

The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.

It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.

Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.

Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.


Choose the surface energy of the exact surface that the adhesive will contact (e.g. if the part was painted metal, paint would be the surface energy).
